Slingshot | Cargo King - Rule the Road

Specifications

Print

GVWR:

Payload Capacity:

Exterior Length:

Exterior Width:

Exterior Height:

Interior Length:

Interior Width:

Interior Height:

Rear Door Type:

Rear Door Width:

Rear Door Height:

Coupler Size:

Curb Weight:

Hitch Weight:

Hitch Height:

Platform Height:

Axle:

Suspension:

Brakes:

Tires:

Wheels:

Main Frame:

Floor:

Walls:

Floorplan:	SLA58SA	SLA510SA	SLA512SA	SLA514SA	SLA68SA	SLA610SA	SLA612SA	SLA614SA	SLA610TA2	SLA612TA2	SLA614TA2	SLA616TA2	SLA710TA2	SLA712TA2	SLA714TA2	SLA716TA2	SLA8516TA2	SLA8518TA2	SLA8520TA2	SLA8522TA2	SLA8524TA2	SLA8520TA3	SLA8522TA3	SLA8524TA3	SLA8526TA3	SLA8528TA3	SLA8530TA3	SLA8532TA3
GVWR:	2990 lb.	2990 lb.	2990 lb.	2990 lb.	2990 lb.	2990 lb.	2990 lb.	2990 lb.	7000 lb.	7000 lb.	7000 lb.	7000 lb.	7000 lb.	7000 lb.	7000 lb.	7000 lb.	7000 lb.	7000 lb.	7000 lb.	7000 lb.	7000 lb.	9800 lb.	9800 lb.	9800 lb.	9800 lb.	9800 lb.	9800 lb.	9800 lb.
Payload Capacity:	2240 lb.	2140 lb.	2065 lb.	1990 lb.	2090 lb.	2040 lb.	1990 lb.	1915 lb.	5700 lb.	5600 lb.	5500 lb.	5400 lb.	5500 lb.	5425 lb.	5350 lb.	5250 lb.	4800 lb.	4700 lb.	4600 lb.	4500 lb.	4300 lb.	6950 lb.	6850 lb.	6750 lb.	6650 lb.	6525 lb.	6350 lb.	6125 lb.
Exterior Length:	12' 0"	14' 0"	16' 0"	18' 0"	12' 0"	14' 0"	16' 0"	18' 0"	14' 0"	16' 0"	18' 0"	20' 0"	14' 0"	16' 0"	18' 0"	20' 0"	20' 0"	22' 0"	24' 0"	26' 0"	28' 0"	24' 0"	26' 0"	28' 0"	30' 0"	32' 0"	34' 0"	36' 0"
Exterior Width:	6' 10"	6' 10"	6' 10"	6' 10"	7' 10"	7' 10"	7' 10"	7' 10"	7' 10"	7' 10"	7' 10"	7' 10"	8' 6"	8' 6"	8' 6"	8' 6"	8' 6"	8' 6"	8' 6"	8' 6"	8' 6"	8' 6"	8' 6"	8' 6"	8' 6"	8' 6"	8' 6"	8' 6"
Exterior Height:	6' 8"	6' 8"	6' 8"	6' 8"	7' 11"	7' 11"	7' 11"	8' 0"	8' 0"	8' 0"	8' 0"	8' 0"	8' 1"	8' 1"	8' 1"	8' 2"	8' 11"	8' 11"	8' 11"	8' 11"	8' 11"	8' 11"	8' 11"	8' 11"	8' 11"	8' 11"	8' 11"	8' 11"
Interior Length:	9' 8"	11' 8"	13' 8"	15' 8"	9' 8"	11' 8"	13' 8"	15' 8"	11' 8"	13' 8"	15' 8"	17' 8"	11' 8"	13' 8"	15' 8"	17' 8"	17' 8"	19' 8"	21' 8"	23' 8"	25' 8"	21' 8"	23' 8"	25' 8"	27' 8"	29' 8"	31' 8"	33' 8"
Interior Width:	4' 9"	4' 9"	4' 9"	4' 9"	5' 9"	5' 9"	5' 9"	5' 9"	5' 9"	5' 9"	5' 9"	5' 9"	6' 9"	6' 9"	6' 9"	6' 9"	8' 1"	8' 1"	8' 1"	8' 1"	8' 1"	8' 1"	8' 1"	8' 1"	8' 1"	8' 1"	8' 1"	8' 1"
Interior Height:	5' 0"	5' 0"	5' 0"	5' 0"	6' 1"	6' 1"	6' 1"	6' 1"	6' 1"	6' 1"	6' 1"	6' 1"	6' 1"	6' 1"	6' 1"	6' 1"	6' 7"	6' 7"	6' 7"	6' 7"	6' 7"	6' 7"	6' 7"	6' 7"	6' 7"	6' 7"	6' 7"	6' 7"
Rear Door Type:	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp	Ramp
Rear Door Width:	4' 3"	4' 3"	4' 3"	4' 3"	5' 4"	5' 4"	5' 4"	5' 4"	5' 4"	5' 4"	5' 4"	5' 4"	6' 4"	6' 4"	6' 4"	6' 4"	7' 8"	7' 8"	7' 8"	7' 8"	7' 8"	7' 8"	7' 8"	7' 8"	7' 8"	7' 8"	7' 8"	7' 8"
Rear Door Height:	4' 9"	4' 9"	4' 9"	4' 9"	5' 10"	5' 10"	5' 10"	5' 10"	5' 10"	5' 10"	5' 10"	5' 10"	5' 10"	5' 10"	5' 10"	5' 10"	6' 11"	6' 11"	6' 11"	6' 11"	6' 11"	6' 11"	6' 11"	6' 11"	6' 11"	6' 11"	6' 11"	6' 11"
Coupler Size:	2"	2"	2"	2"	2"	2"	2"	2"	2 5/16"	2 5/16"	2 5/16"	2 5/16"	2 5/16"	2 5/16"	2 5/16"	2 5/16"	2 5/16"	2 5/16"	2 5/16"	2 5/16"	2 5/16"	2 5/16"	2 5/16"	2 5/16"	2 5/16"	2 5/16"	2 5/16"	2 5/16"
Curb Weight:	TBD	TBD	925 lb.	1000 lb.	900 lb.	950 lb.	1000 lb.	1075 lb.	1300 lb.	1400 lb.	1500 lb.	1600 lb.	1500 lb.	1575 lb.	1650 lb.	1750 lb.	2200 lb.	2300 lb.	2400 lb.	2500 lb.	2700 lb.	2850 lb.	2950 lb.	3050 lb.	3150 lb.	3275 lb.	3450 lb.	3675 lb.
Hitch Weight:	90 lb.	102 lb.	111 lb.	120 lb.	108 lb.	114 lb.	120 lb.	129 lb.	156 lb.	168 lb.	180 lb.	192 lb.	180 lb.	189 lb.	198 lb.	210 lb.	264 lb.	276 lb.	288 lb.	300 lb.	324 lb.	342 lb.	354 lb.	366 lb.	378 lb.	20 lb.	414 lb.	441 lb.
Hitch Height:	14"	14"	14"	14"	14"	14"	14"	15"	15"	15"	15"	15"	19"	19"	19"	20"	18"	18"	18"	18"	18"	20"	20"	20"	20"	20"	20"	20"
Platform Height:	18"	18"	18"	18"	18"	18"	18"	19"	19"	19"	19"	19"	22"	22"	22"	23"	21"	21"	21"	21"	23"	23"	23"	23"	23"	23"	23"	23"
Axle:	3500	3500	3500	3500	3500	3500	3500	3500	2-3500 lbs	2-3500 lbs	2-3500 lbs	2-3500 lbs	2-3500 lbs	2-3500 lbs	2-3500 lbs	2-3500 lbs	2-3500 lbs	2-3500 lbs	2-3500 lbs	2-3500 lbs	2-3500 lbs	2-5200 lbs	2-5200 lbs	2-5200 lbs	2-5200 lbs	2-5200 lbs	2-5200	2-5200 lbs
Suspension:	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD	TBD
Brakes:	Optional	Optional	Optional	Optional	Optional	Optional	Optional	Optional	Electric	Electric	Electric	Electric	Electric	Electric	Electric	Electric	Electric	Electric	Electric	Electric	Electric	Electric	Electric	Electric	Electric	Electric	Electric	Electric
Tires:	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST205/75R15/C	ST225/75R15/C	ST225/75R15/C	ST225/75R15	ST225/75R15/C	ST225/75R15/C
Wheels:	5 Bolt Aluminum	5 Bolt Aluminum	5 Bolt Aluminum	5 Bolt Aluminum	5 Bolt Aluminum	5 Bolt Aluminum	5 Bolt Aluminum	5 Bolt Aluminum	5 Bolt Aluminum	5 Bolt Aluminum	5 Bolt Aluminum	5 Bolt Aluminum	5 Bolt Aluminum	5 Bolt Aluminum	5 Bolt Aluminum	5 Bolt Aluminum	5 Bolt Aluminum	5 Bolt Aluminum	5 Bolt Aluminum	5 Bolt Aluminum	5 Bolt Aluminum	6 Bolt Aluminum	6 Bolt Alum	6 Bolt Alum	6 Bolt Alum	6 Bolt Alum	6 Bolt Alum	6 Bolt Alum
Main Frame:	2" x 3" Tube	2" x 3" Tube	2" x 3" Tube	2" x 3" Tube	2" x 3" Tube	2" x 3" Tube	2" x 3" Tube	2" x 4" Tube	2" x 4" Tube	2" x 4" Tube	2" x 4" Tube	2" x 4" Tube	2" x 4" Tube	2" x 4" Tube	2" x 4" Tube	2" x 5" Tube	2" x 5" Tube	2" x 5" Tube	2" x 5" Tube	2" x 5" Tube	2" x 5" Tube	2" x 7" Tube	2" x 7" Tube	2" x 7" Tube	2" x 7" Tube	2" x 7" Tube	2" x 7" Tube	2" x 7" Tube
Floor:	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood	3/4" Plywood
Walls:	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl	White Vinyl

Features & Options

Print

16” O/C Aluminum Studs In Wall, Roof,& Floor
Aerodynamic 24” Slanted Wedge Front
Independent Torsion Axle w/EZ Lube Hubs
Aluminum Alloy Wheels With Radial Tires
Ramp Door W/Flap Standard (Optional Aluminum Frame Double Doors / No Added Charge)
3/4” Plywood Floor
“Insulated” White Vinyl Wall W/ Alum Trim
“Insulated” White Vinyl Ceiling W/ Alum Trim
RV Style Door With Flushlock
24” Slanted ATP Stoneguard
Bonded .030 Aluminum Exterior
One Piece Aluminum Roof
(2) LED Interior Dome Light w/Switch
LED Exterior Lights
(1) Roof Vent
8’ 6” Wides Include
Heavy Duty Triple Tube Tongue
Beavertail
2 Extra LED Dome Lights & Switch (4 Lights, 2 Switch, Total)
1 Additional Roof Vent (2 Total)
2 Flowthru Sidewall Vents
(4) 5K D-Rings
