Defender

Classic cargo lines that stand the test of time but won’t test your budget.

Care Camps, fighting cancer and making memories

Specifications

Print

Floorplan:DE58SADE510SADE610SADE612SADE610TA2DE612TA2DE710TA2DE712TA2DE714TA2DE716TA2DE816TA2DE818TA2DE820TA2DE822TA2DE824TA2
GVWR:2990 lb.2990 lb.2990 lb.2990 lb.7000 lb.7000 lb.7000 lb.7000 lb.7000 lb.7000 lb.7000 lb.7000 lb.7000 lb.7000 lb.7000 lb.
Payload Capacity:2040 lb.1965 lb.1790 lb.1690 lb.5350 lb.5200 lb.5075 lb.4900 lb.4725 lb.4550 lb.4400 lb.4250 lb.4100 lb.3950 lb.3800 lb.
Exterior Length:11' 10"13' 10"13' 10"15' 10"13' 10"15' 10"13' 10"15' 10"17' 10"19' 10"19' 10"21' 10"23' 10"25' 10"27' 10"
Exterior Width:7' 0"7' 0"8' 0"8' 0"8' 0"8' 0"8' 6"8' 6"8' 6"8' 6"8' 6"8' 6"8' 6"8' 6"8' 6"
Exterior Height:6' 5"6' 5"7' 9"7' 9"8' 3"8' 3"8' 6"8' 6"8' 6"8' 6"8' 6"8' 6"8' 6"8' 6"8' 6"
Interior Length:8' 7"10' 7"10' 7"10' 7"10' 7"12' 7"10' 7"12' 7"14' 7"16' 7"16' 7"18' 7"20' 7"22' 7"24' 7"
Interior Width:4' 8"4' 8"5' 8"5' 8"5' 8"5' 8"6' 8"6' 8"6' 8"6' 8"7' 6"7' 6"7' 6"7' 6"7' 6"
Interior Height:4' 10"4' 10"6' 2"6' 2"6' 8"6' 8"6' 9"6' 9"6' 9"6' 7"6' 7"6' 7"6' 7"6' 7"6' 7"
Rear Door Type:DoubleDoubleDoubleDoubleDoubleDoubleDoubleDoubleDoubleDoubleDoubleDoubleDoubleDoubleDouble
Rear Door Width:4' 4"4' 4"5' 4"5' 4"5' 4"5' 4"6' 4"6' 4"6' 4"6' 4"7' 1"7' 1"7' 1"7' 1"7' 1"
Rear Door Height:4' 2"4' 2"5' 6"5' 6"6' 0"6' 0"6' 1"6' 1"6' 1"5' 11"5' 11"5' 11"5' 11"5' 11"5' 11"
Coupler Size:2"2"2"2"2-5/16"2 5/16"2 5/16"2-5/16"2 5/16"2 5/16"2 5/16"2 5/16"2 5/16"2 5/16"2 5/16"
Curb Weight:950 lb.1025 lb.1200 lb.1300 lb.1650 lb.1800 lb.1925 lb.2100 lb.2275 lb.2450 lb.2600 lb.2750 lb.2900 lb.3050 lb.3200 lb.
Hitch Weight:95 lb.103 lb.120 lb.130 lb.165 lb.180 lb.193 lb.210 lb.228 lb.245 lb.260 lb.275 lb.290 lb.305 lb.320 lb.
Hitch Height:17"17"17"17"18"18"18"18"18"20"20"20"20"20"20"
Platform Height:17"17"17"17"18"18"18"18"18"20"20"20"20"20"20"
Axle:299029902990299035003500350035003500350035003500350035003500
Suspension:TBDTBDTBDTBDTBDTBDTBDTBDTBDTBDTBDTBDTBDTBDTBD
Brakes:OptionalOptionalOptionalOptionalElectricElectricElectricElectricElectricElectricElectricElectricElectricElectricElectric
Tires:ST205/75R15/CST205/75R15/CST205/75R15/CST205/75R15/CST205/75R15/CST205/75R15/CST205/75R15/CST205/75R15/CST205/75R15/CST205/75R15/CST205/75R15/CST205/75R15/CST205/75R15/CST205/75R15/CST205/75R15/C
Wheels:5 Bolt5 Bolt5 Bolt5 Bolt5 Bolt5 Bolt5 Bolt5 Bolt5 Bolt5 Bolt5 Bolt5 Bolt5 Bolt5 Bolt5 Bolt
Main Frame:3" Tube3" Tube3" Tube3" Tube4" Tube4" Tube4" Tube4" Tube4" Tube6" I-Beam6" I-Beam6" I-Beam6" I-Beam6" I-Beam6" I-Beam
Floor:3/4" Plywood3/4" Plywood3/4" Plywood3/4" Plywood3/4" Plywood3/4" Plywood3/4" Plywood3/4" Plywood3/4" Plywood3/4" Plywood3/4" Plywood3/4" Plywood3/4" Plywood3/4" Plywood3/4" Plywood
Walls:3/8" Plywood3/8" Plywood3/8" Plywood3/8" Plywood3/8" Plywood3/8" Plywood3/8" Plywood3/8" Plywood3/8" Plywood3/8" Plywood3/8" Plywood3/8" Plywood3/8" Plywood3/8" Plywood3/8" Plywood

Features & Options

Print
  • Double Rear Doors (Opt. Ramp Available)
  • Semi Style Camlock Door Latch on Rear Doors
  • Door Hold-Backs on All Doors
  • Leaf-Spring Axles
  • All-Wheel Electric Brakes w/Breakaway*
  • 12-Volt Breakaway Switch with Battery*
  • Silver Powder Coated Wheels
  • Chrome Center Caps
  • Radial Tires
  • Galvanized Roof
  • Colored Aluminum or ATP Top Wrap
  • RV Style C/S Door (24" on 5 wide, 32" on 6 wide, 36" on 7 & 8 wide)
  • 24" Stoneguard
  • 2 – Interior LED Dome Lights, & 1 – Wall Switch
  • Roof Vent
  • 3/8" Plywood Walls with Lauan Trim
  • ATP Exterior Aluminum Fenders
  • Radius Fiberglass Front Cap
  • Clear Lens LED Clearance Lights
  • Clear Lens LED Strip Tail Lights
  • .030 Aluminum Exterior
  • Colored Aluminum Wrap on Rear
  • Undercoated Frame
  • Tongue Jack w/ Sand Pad
  • Steel Sealed Sidewalls
  • Welded Safety Chains
  • 16" O/C Roof Upgrade
  • One-Piece Aluminum Roof
  • (2) LED Loading Lights with switch
  • (2) Stabilizer Jacks Under Rear Corners
  • 6" of ATP Along Exterior Bottom of Sidewalls
  • Rear Ramp Door
  • Beavertail
  • 102" Wide Upgrade
  • 16" O/C Floor
  • (4) LED Dome Lights - (2) Switches (Total)
  • (2) Roof Vents (Total)
  • (4) 5,000 lb. D-Rings
  • Triple Tube Tongue
  • Aluminum Roof
  • 6" ATP on Bottom
  • ATP Front Corners
  • Anodized Rear Hoop
  • All 110-Volt Packages require a finished ceiling
  • (2) 4' Fluorescent Lights with (1) Wall Switch
  • (2) Interior Wall Recepts
  • Exterior Wall Recept with GFI
  • With Lifeline and Motorbase Plug
  • All 110-Volt Packages require a finished ceiling
  • White Vinyl Ceiling Liner
  • White Aluminum Wall Liner
  • Vinyl Flooring
  • Aluminum Tread Plate on Ramp and Flap
  • Rear Ramp Door
  • One Piece Flat Top Aluminum Roof
  • Low Rider Pan in Rear
  • Flushlock
  • White Vinyl Walls and Ceiling
  • V-Nose Front with Anodized Nose
  • 4' Overhead Cabinet in V-Nose
  • 6-5,000 lb. D-Rings
  • Black RTP Floor
  • Freezer Latches on Rear Ramp
  • 2 - Flow Thru Vents IPO Roof Vents
  • Drop Down Corner Post Jacks
  • 4 - Recessed LED Dome Lights w/ 2 Switches
  • 2 - 12 Volt Loading Lights
  • Orange or Gold Flame Graphics
  • 24" Smooth Anodized on Sides
  • Anodized Rear Hoop
  • 2 - Wheel Chocks Shipped Loose
  • 81" Overall Exterior Height
  • 16" O/C Roof
  • 16" O/C Floor Members
  • 60" Triple Tube Tongue
  • 3/4" Plywood Walls
  • (2) LED Loading Lights with switch
  • (2) 2-Way Sidewall Vents (Aluminum)
  • (3) Aluminum Ladder Rack Sections
  • (2) 2-Way Sidewall Vents (Aluminum)
  • (2) Non-Powered Roof Vents
  • 48" RV Door Upgrade
  • 54" Extended Triple-Tube Tongue
  • 16" O/C Floor Upgrade
  • Rear Ramp Door with Spring Assist
  • (2) 12V LED Dome Lights (Total of 4)
  • (1) Wall Switch (Total of 2)
  • Surface Wall Mount E-Track (1 Row on Each Sidewall)
  • Shelf Across Front of Trailer (24" Deep with 3" Lip)
  • (2) 2-Way Sidewall Vents (Aluminum)
  • (1) Non-Powered Roof Vent
  • 54" Extended Triple-Tube Tongue
  • 16" O/C Floor Upgrade
  • 16" O/C Roof Upgrade
  • Rear Ramp Door with Spring Assist
  • (2) 12V LED Dome Lights (Total of 4)
  • (1) Wall Switch (Total of 2)
  • (2) 2-Way Sidewall Vents (Aluminum)
  • (1) Non-Powered Roof Vent (Total of 2)
  • 60" Extended Triple-Tube Tongue
  • 16" O/C Floor Upgrade
  • 16" O/C Roof Upgrade
  • Reinforced Rear Ramp Door with Spring Assist
  • (2) 12V LED Dome Lights (Total of 4)
  • (1) Wall Switch (Total of 2)
  • Extra Grab Handle on Rear Ramp Door
  • 3/4" Plywood Kickplate on Interior Walls
  • Surface Mount E-Track on Sidewalls, 1 Row Per Wall
  • Locking Hasps on Side and Rear Doors
